Ingress Protection*

IP66

Operating Temperature

-10°C to 50°C / 14°F to 122°F

GPS Performance

1575.42Mhz (L1, C/A code)
66-channels, built-in WAAS / EGNOS / MSAS / GAGAN Demodulator
Sensitivity better than -165dBm
Built-in active antenna

Positioning Ability*


Cold Start: 35 seconds
Warm Start: 32 seconds
Hot Start: 1 second
Reacquisition: <1 second
Non DGPS (Differential GPS): 2.5m/CEP(50%) 8.0m/CEP(95%)
With DGPS corrected (EGNOS / WAAS): 1.5m/CEP(30-50%) 2.5m/CEP(95%)

Storage Card


MicroSD, MicroSDHC, MicroSDXC
FAT16, FAT32 file format.

Logging Data

Geodesics WGS-84
Date
Time
Latitude: (0.000001 degree)
Longitude: (0.000001 degree)
Altitude: -1,000 ~ 18,000 meters -3280 ~ 59000 ft (1 meters / 3ft)
Speed: 0 ~ 1,850 km/h; 0~1180 mi/h (0.1km / 0.1mi)
Heading: 0 ~ 359 (1 degree)

Waypoints Amount*

1. CSV (plain code format): 580 Million points
2. GPX (common exchange format): 310 Million points
3. NMEA (NMEA-0183): 210 Million points

Dependability*

Better than 99.998%*

Power and Battery

Built-in 1900mAh rechargeable lithium-polymer battery
Normal Mode*: 60-65 hours
Spy Tracking Mode: Approx 21 days (10 minutes interval); Approx 27 days (30 minutesinterval); Approx 30 days (60 minutes interval);
Charging time: Approx 3.5 hours
Power Supplies: DC 5V 800mA

System Requirements

Internet access
Mac: OS X v10.7 or later
PC: Windows 7 or later
Linux: 2.6.12 or later

Parts Description
